Balanced Pressure Steam Trap

DSC CAST IRON BALANCED PRESSURE THERMOSTATIC STEAM TRAPS No. S50、S50F ●CAST IRON BODY AND CAP, ALL S.S. INTERNALS. ●MOP 17K x 230 °C.. ●EXCELLENT CORROSION RESISTANCE. ●EXCELLENT RESISTANCE TO HYDRAULIC SHOCKS. ●DO NOT VENT AIR AND CO2 AT STEAM TEMPERATURE. ●GOOD OPERATION AGAINST BACK PRESSURE. ●GOOD RESISTANCE TO DAMAGE FROM FREEZING ●DELAYED RESPONSIVENESS TO SLUGS OF CONDENSATE. ●SMALL COMPARATIVE PHYSICAL SIZE. DSC CATALOG No.S50

DSC CAST STEEL BALANCED PRESSURE THERMOSTATIC STEAM TRAPS No. S61、S61F        ●CAST STEEL BODY AND CAP, ALL S.S. INTERNALS. ●MOP 22K x 320 °C. ●FAIR ENERGY CONSERVATION. ●FAIR RESISTANCE TO WEAR. ●GOOD CORROSION RESISTANCE. ●EXCELLENT OPERATION AGAINST BACK PRESSURE, RESISTANCE TO DAMAGE FROM FREEZING,GOOD ABILITY TO PURGE SYSTEM. ●DELAYED RESPONSIVENESS TO SLUGS OF CONDENSATE. ●FAIR ABILITY TO HANDLE DIRT.CATALOG DSC No.S61

DSC ALL STAINLESS STEEL  BALANCED PRESSURE THERMOSTATIC STEAM TRAPS No. S70        ●ALL S.S. BODY AND CAP, ALL S.S. INTERNALS. ●MOP 32K x 320 °C. ●FAIR ENERGY CONSERVATION. ●FAIR RESISTANCE TO WEAR. ●GOOD CORROSION RESISTANCE. ●DO NOT VENT AIR AND CO2 AT STEAM TEMPERATURE. ●EXCELLENT OPERATION AGAINST BACK PRESSURE, RESISTANCE TO DAMAGE FROM FREEZING, GOOD ABILITY TO PURGE SYSTEM. ●DELAYED RESPONSIVENESS TO SLUGS OF CONDENSATE. ●FAIR ABILITY TO HANDLE DIRT. ●SMALL COMPARATIVE PHYSICAL SIZE.DSC CATALOG No.S70

DSC ALL STAINLESS STEEL  BALANCED PRESSURE THERMOSTATIC STEAM TRAPS No. S72、S72F        ●ALL S.S. BODY AND CAP, ALL S.S. INTERNALS. ●MOP 32K x 320 °C. ●SMALL DRIBBLE AT NO LOAD, INTERMITTENT AT LIGHT AND NORMAL LOAD, CONTINUOUS AT FULL LOAD. ●EXCELLENT CORROSION RESISTANCE. ●EXCELLENT RESISTANCE TO HYDRAULIC SHOCKS. ●DO NOT VENT AIR AND CO2 AT STEAM TEMPERATURE. ●GOOD OPERATION AGAINST BACK PRESSURE. ●GOOD RESISTANCE TO DAMAGE FROM FREEZING. ●DELAYED RESPONSIVENESS TO SLUGS OF CONDENSATE. ●SMALL COMPARATIVE PHYSICAL SIZE.DSC CATALOG No.S72

DSC ALL STAINLESS STEEL BALANCED PRESSURE THERMOSTATIC STEAM TRAP WITH UNIVERSAL CONNECTOR No. S79、S79F      ●ALL S.S. BODY AND CAP, ALL S.S. INTERNALS. ●MOP 32K x 320 °C. ●DSC S79 ALL STAINLESS STEEL BALANCED PRESSURE THERMOSTATIC STEAM TRAP WITH UNIVERSAL CONNECTOR. THERMOSTATIC WELDED UNIT CAN BE REPLACED WITHOUT DISTURBING PIPE . ●EXCELLENT CORROSION RESISTANCE. ●EXCELLENT RESISTANCE TO HYDRAULIC SHOCKS. ●NOT VENT AIR AND CO2 AT STEAM TEMPERATURE. ●GOOD OPERATION AGAINST BACK PRESSURE. ●GOOD RESISTANCE TO DAMAGE FROM FREEZING. ●DELAYED RESPONSIVENESS TO SLUGS OF CONDENSATE. ●ONE YEAR SATISFACTORY SERVICE GUARANTEED. ●INTERNAL CHECK VALVE OPTIONAL.DSC CATALOG No.S79

DSC FORGED STEEL BALANCED PRESSURE THERMOSTATIC STEAM TRAP No. S80、S80F ●FORGED STEEL BODY AND CAP, ALL S.S. INTERNALS. ●MOP 32K x 320 °C.. ●FAIR ENERGY CONSERVATION. ●FAIR RESISTANCE TO WEAR. ●NOT VENT AIR AND CO2 AT STEAM TEMPERATURE. ●EXCELLENT OPERATION AGAINST BACK PRESSURE, RESISTANCE TO DAMAGE FROM FREEZING, GOOD ABILITY TO PURGE SYSTEM. ●DELAYED RESPONSIVENESS TO SLUG OF CONDENSATE. ●FAIR ABILITY TO HANDLE DIRT. ●NOT FOR SUPERHEATED STEAM SERVICE. ●PERFORATED STRAINER CAN BE CLEANED AFTER CAP REMOVED. ●INTERNAL CHECK VALVE OPTIONAL.DSC CATALOG No.S80
